Download IRIS Instruments Electre Pro v02.09.01
Electre Pro software full crack license download, ELECTRE Pro is a software developed by IRIS Instruments for designing and generating multi-electrode measurement sequences for electrical resistivity and induced polarization (IP) systems such as SYSCAL Pro / ELREC Pro Switch and similar IRIS devices. It allows you to prepare the entire measuring sequence before going to the field, then upload it to the instrument.
Main Features and Capabilities of Electre Pro
1. Electrode Array Selection
ELECTRE Pro supports all standard and custom electrode arrays, including:
- Dipole–Dipole
- Wenner / Schlumberger (Reciprocal)
- Pole–Dipole (forward & reverse)
- Pole–Pole
- Cross-diagonal arrays
- Custom non-standard arrays (manually defined)
This is useful for tailoring the geometry based on your project’s target depth and resolution.
2. Define Investigation Depth & Measurement Levels
- Maximum investigation depth
- Electrode spacing (multi-spacing)
- Number of levels / depths of investigation
The software automatically generates an optimized sequence based on your desired depth and array configuration.
3. Graphical Visualization
ELECTRE Pro provides:
- A graphical display of electrode positions
- Visual representation of the entire measurement sequence
- Optional animation to simulate how current injection and potential measurements proceed step-by-step in the field
This helps verify the survey design before actual data collection.
4. Sequence Optimization
The software optimizes the measurement order to:
- Reduce survey time
- Minimize electrode switching
- Improve data quality for multi-electrode / multi-channel systems
It also supports importing external sequence files (.txt or custom formats) for complex or non-standard setups.
5. Supports 2D, 3D, Surface, and Borehole Surveys
ELECTRE Pro can create sequences for:
- 2D surface resistivity sections
- 3D resistivity grids
- Combined surface + borehole surveys
- Downhole / cross-hole arrays
This makes it suitable for a wide range of geophysical applications.
Typical Field Applications
ELECTRE Pro is used in combination with IRIS Instruments equipment for:
✔ Environmental studies
- Contamination mapping
- Soil characterization
- Landfill investigations
✔ Groundwater exploration
- Aquifer detection
- Fault and fracture mapping
- Determining depth to bedrock
✔ Geotechnical & civil engineering
- Foundation analysis
- Bedrock depth estimation
- Tunnel and infrastructure planning
✔ Mining & mineral exploration
- Mapping ore bodies
- Structure and fault detection
- Resistivity/IP surveys for mineral exploration
IRIS Instruments Electre Pro v02.09.01
Electre Pro software details:
- Operating system: Windows 10, 11 x86-x64
- Crack: Full Crack (unlimited PCs)
- File Size: 54.6 MB + 60 MB
